技术规格：

SENSOR: 14 MEGAPIXEL MYSTERIUM-X™

PIXEL ARRAY: 5120 (h) x 2700 (v)

DYNAMIC RANGE: 13.5 stops, up to 18 stops with HDRx™

6 fps with 5K FF and HDRx on

12 fps with 4K HD and HDRx™ on

MAX IMAGE AREA: 5120 (h) x 2700 (v)

LENS COVERAGE: 27.7mm (h) x 14.6mm (v) = 31.4 mm (d)

LENS MOUNT: DSMC Lens Mount

MAX DEPTH OF FIELD: Equivalent to S35mm (Motion) / APS-H (Still) lenses

ACQUISITION FORMATS: 5K FF REDCODE RAW (Full Frame)

4K HD REDCODE RAW

3K HD REDCODE RAW

1080p REDCODE RAW

1K REDCODE RAW

PROJECT FRAME RATES: 23.98, 24, 25, 29.97, 47.96, 48, 50, 59.97

MONITOR/PROGRAM OUTPUT: HD-SDI and HDMI with Frame Guides and Look Around or Clean Feed 1080p 4:2:2, 720p 4:2:2 SMPTE Timecode, HANC Metadata, 24-bit 48Khz Audio

DIGITAL MEDIA REDMAG (SSD) Module: (48, 64, 128, 256 and 512GB Media)

REDCODE™ 16-bit RAW Processing: Compression choices of 18:1 to 3:1

1-12 fps 5K FF

1-30 fps 4K HD

1-48 fps 3K HD

1-60 fps 1080p HD

1-120 fps 1K

AUDIO: 2 channel, uncompressed, 24 bit, 48KHz.

Optional 4 channel, and AES / EBU digital audio.

MONITORING OPTIONS: RED LCD 5"/9" Touchscreen Display

BOMB EVF™ High Definition Viewfinder

REMOTE CONTROL: REDLINK Wireless, Ethernet, RS232, GPI Trigger

WEIGHT: 5lbs. Body only

CONSTRUCTION: Aluminum Alloy

COLOR: Battleship Gray Brain Body, DSMC Lens Mount (Black Aluminum/Silver Titanium) and Black Side SSD. All DSMC Modules Black

TEMPERATURE RANGES: Operating Range: 0�0�8C to +40�0�8C (32�0�8F to 104�0�8F)

Storage Range: -20�0�8C to +50�0�8C (-4�0�8F to 122�0�8F)
